p2.5 floor standing indoor led display retail solution WIFI 4G USB led poster portable digital signage smart led iposter
Function and Technology Character Introduction:
1. P2.5 indoor led advertising machine high brightness, high contrast, high gray scale, the surface of high light transmission LED indoor module powerful high-end display products, through the network cable, USB Disk, WiFi, 4G (remote) to control and update the data. Plug and play don't need installation.
2. p2.5mm indoor LED display service life of more than 10 million hours is double the service life of splicing wall and unlike splicing wall that after aging replacement lamp back light or replacement of lighting,
3. Save operation costs, information update is timely
4. Animated advertising is more likely to create amazing role
5. LED uses cold light-emitting technology, the brightness of outdoor LED display is greater than 8000mcd㎡ .
Products Applications:
Widely used in shopping malls, catering industry, product launches, weddings, hotels, airports, luxury stores, chain stores, reception halls, mobile screens, real-time video, catering industry, reception halls, product launches, mobile screens, chain stores, etc.
SPECIFICATIONS Parameters:
| Product parameter |
| led module | |
| Pixel pitch (mm) | P2.5 |
| Pixel density (point /㎡) | 160000 |
| Module size (mm) | |
| Module resolution (WxH) | 128X64 |
| Package form | SMD2020 |
| scanning method | 1/32S |
| Refresh rate (Hz) | ≥1920/3840(Optional) |
| White balance brightness (Nits) | ＞800 |
| Color temperature (K) | 3200-9300(Adjustable ) |
| Gray scale | ≥14bit |
| Frame change frequency | 60-120Hz |
| Viewing angle (horizontal/vertical) | 160°/160° |
| Protection level (front/back) | IP31 |
| Average/peak power consumption (W/㎡) | 850/350 |
| Face mask | NO |
| cabinet | |
| cabinet size (mm) | 640X1920 |
| Screen weight (Kg) | 15 |
| cabinet module composition (WxH) | 2X12 |
| Cabinet resolution (WxH) | 256X768 |
| Flatness (mm) | ≤0.2 |
| Maintenance method | Pre-maintenance |
| cabinet material | Die-cast aluminum |
| Application Environment | |
| Input voltage (V) | 110-240 |
| Operating temperature (℃) | -20~50 |
| Working humidity (RH) | 10%-95% |
| Service life (H) | ≥100000 |
| Model type (using video processor) | AV,S-Video,VGA,DVI,HDMI,SDI,DP |
| Control distance | Category 5 network cable :＜100m,Single mode fiber :＜10km |
| certified product |
 |
Weiye poster series led strip display screen advantage:
1. Help to increase product sales and brand visibility and popularity
2. indoor viewing angle can be greater than 160 degrees, outdoor viewing angle can be greater than 120 degrees.
3. Enhance interaction with customers
4. Intelligent adjustment of screen brightness
5. Update the playback in real time, and ensure that the information conveys high efficiency
